Offering accurate firepower

from a light stabilized platform the Remote Controlled Weapon Platform NIMROD is ideally suited for small and medium sized vehicles. It is intended to bridge the gap between weapon stations and heavy gun turrets, offering  high precision and superior engagement ranges at an affordable price.

To this end the platform is highly modular. It can be equipped with a 25mmx137 or 30mmx173 cannon and the sensors can be selected to offer the best possible value or superior performance depending on operational needs and budget.

Despite its lightweight design

and compact dimensions the platform can pack the full punch from the 30mmx173 caliber, allowing for engagements up to 3,000m. This caliber offers the use of a wide range of ammunition types such as the anti-armor APFSDS-T round that provides ample armor penetration against current and future battlefield threats. If all up station weight is critical the 25mmx137 caliber can be integrated. This configuration still offers engagement ranges up to 2500m.

The station is equipped with a state of the art electro-optical sensor unit, which allow for quick target acquisition and visual identification. In its base configuration, the sensors offered are balanced to utilize the full potential of the cannon range and firepower. The modular design allows for selecting the ideal protection level and sensor suite, based on mission needs and priority.

A CoAx machine gun

can be fitted and space is provided for an anti-tank missile of choice.

Industrial localization can be easily offered and the highly modular design makes integration of locally produced components straightforward. We can offer the finished Platform or kits for local assembly.

We are currently integrating the KCE and KBA cannons offered by Rheinmetall in a Concept Demonstrator that will be revealed shortly. Valhalla can offer integration studies for other weapons upon demand.

Ammo Ready for Use

30mm × 173: 180 rounds
25 × 137: 270 rounds

Specification

Height (station only): 932mm
Width (station only): 1500mm
Length: 1181mm
Swing radius: 2014mm
Weight with gun and ammunition: 850kg (depend on configuration)

Elevation

Range: -15° / +50° (depend on main weapon)
Limitation could be rise on vehicle installation constrains
Min Speed: < 0.2 mrad/sec
Max Speed: > 1.5 rad/sec

Traverse

Azimuth: n × 360°
Min Speed: < 0.2 mrad/sec
Max Speed: > 1.5 rad/sec

Stabilization

Elevation: Typical better than 1.2 mrad (RMS) on track at 20 km/h (vehicle dependent)
Traverse: Typical better than 1.2 mrad (RMS) on track at 20 km/h (vehicle dependent)

Aiming

Accuracy: < 0.3 mrad

Input Voltage

18 ~ 32 VDC

Environmental Conditions

According to MIL-STD-810G

Electromagnetic Interface

According to MIL-STD-461F

Armor Protection

STANAG 4569 level 2 or 3

Armament

Rheinmetall KCE 30 x 173

Un-Cooled LWIR Thermal Camera

Sensor: Cooled MWIR Thermal Imager
Field of view Wide: 15.3°(H) x 12.2° (V), Middle: 4.9°(H) x 3.9° (V), Narrow: 1.2° (H) x 0.96° (V)
Video output: Analog - PAL or NTSC /Digital: H.264 over IP*
Detection/Recognition/Identification for NATO size target: 20km / 7,1km / 4,3km
Detection/Recognition/Identification for human size target: 9km / 2.9km / 1.7km

Day/Night Camera

Resolution: 1920 x 1080, 2 Megapixels
Sensitivity Color: 0.1 lx (F1.6, AGC on, 1/30s), High Sensitivity Mode Color: 0.01 lx (F1.6, AGC on, 1/30s)
Continuous optical zoom: 30x optical zoom
Continuous digital zoom: 12x digital zoom
Lens: f=4.3mm (wide) to 129.00 mm (tele); F1.6 to F4.7
Field of View: 63.7° (wide end) to 2.3°(tele end) – horizontal

Laser Rangefinder LDC0/10

Measurement range: 50m – 20 000m
Measurement range (Standard target): 10 000m – Target size 2.3 x 2.3 m, visibility 15 km, target reflectivity 30%, detection probability >90%
Precision: 5 m
Beam divergence 0.35 mrad
Wave length 1.5 µm
Measurement rates: 40 per minute
Eye safety: Laser Class 1 (EN 60825-1:2014) (IEC 60825-1:2014DATA RECORDER)
Operating temperature: -32°C + 55°C

Armament

2A42 30mm x 165

Un-Cooled LWIR Thermal Camera

Sensor: Cooled MWIR Thermal Imager
Field of view Wide: 15.3°(H) x 12.2° (V), Middle: 4.9°(H) x 3.9° (V), Narrow: 1.2° (H) x 0.96° (V)
Video output: Analog - PAL or NTSC /Digital: H.264 over IP*
Detection/Recognition/Identification for NATO size target: 20km / 7,1km / 4,3km
Detection/Recognition/Identification for human size target: 9km / 2.9km / 1.7km

Day/Night Camera

Resolution: 1920 x 1080, 2 Megapixels
Sensitivity Color: 0.1 lx (F1.6, AGC on, 1/30s), High Sensitivity Mode Color: 0.01 lx (F1.6, AGC on, 1/30s)
Continuous optical zoom: 30x optical zoom
Continuous digital zoom: 12x digital zoom
Lens: f=4.3mm (wide) to 129.00 mm (tele); F1.6 to F4.7
Field of View: 63.7° (wide end) to 2.3°(tele end) – horizontal

Laser Rangefinder LDC0/10

Measurement range: 50m – 20 000m
Measurement range (Standard target): 10 000m – Target size 2.3 x 2.3 m, visibility 15 km, target reflectivity 30%, detection probability >90%
Precision: 5 m
Beam divergence 0.35 mrad
Wave length 1.5 µm
Measurement rates: 40 per minute
Eye safety: Laser Class 1 (EN 60825-1:2014) (IEC 60825-1:2014DATA RECORDER)
Operating temperature: -32°C + 55°C
